Air operated Pinch Valves with internal thread connection

The air operated pinch valves with internal thread connection are available in the nominal diameters of DN10 to DN125. They are designed with an internal thread according to DIN ISO 228 and ANSI / ASME B1.20.1 (NPT) as standard.

The general description of air operated pinch valves covers the operation and the benefits of air pinch valves with a internal thread connection.

Layout of the air operated pinch valve with internal thread connection

The structure of the air operated pinch valves with internal thread connection encompasses the sleeve - the essential part of every pinch valve - a body and two collar caps. The pinch sleeve is positioned in the centre of the air operated pinch valve body; both of its ends are pressed in by the collar caps, thus forming a compact unit.

At present AKO offers 4 different series of Air Pinch Valves with internal thread connection

The VMC series is available in nominal diameters DN10 to DN100.
The VMC series of air operated pinch valve with internal thread connection consists of a powder-coated aluminium body or alternatively an electro-polished stainless steel body, a fibre-reinforced pinch sleeve, two collar caps made either from pure POM (polyoxymethylene), electrically conductive POM or stainless steel.

The VMP series is available in nominal diameters DN10 to DN50.
The VMP series has a three-part plastic body, a fibre-reinforced pinch sleeve and two plastic coupling sleeve covers. The following plastic materials are available:

  • White POM (polyoxymethylene)
  • Black POM, weather resistant
  • Electrically conducting POM

The VM series is also available in nominal diameters DN10 to DN50.
The VM series consists of PVC (polyvinyl chloride).

The VF series with female thread connection is available in nominal diameters DN40 to DN100.
The VF series has a powder-coated aluminium body, a fibre-reinforced pinch sleeve, two powder-coated aluminium flanges with a female thread.

VMC Series
VMP Series
VM Series
VF Series

Industrial sectors, possible applications:

  • Farming
  • Food industry
  • Paper industry
  • Textile industry
  • Wood industry
  • Tobacco industry
  • Recycling industry
  • Waste industry
  • Printing industry
  • Chemistry
